Introducing the Icon Panel
Introducing the Icon Panel
The Icon Panel is the principal component of ASP’s signature Icon Series. The Icon Panels’ patented design features have revolutionised the access floor industry.
Outstanding static and live load performance
Panel design allows for fast precise installation
Non-combustible
Molsture resistant
Ease of maintenance and serviceability with interchangeable panels
Superior durability and Iifespan contributing to a significant reduction in ife oycle costs
Excellent earthing continuity
High recycled content
Contributes significantly to Green Star and LEED requirements through a completed product LCA & EPD
Patented design features create a quietand comfortable underfoot solution
Explore the Icon Access Floor Systems
The Panel Construction
SIZE 600mm x 600mm
DEPTH 33mm
CONSTRUCTION
The panels consist of a hardened steel top and bottom sheet plate with corrosion-resistant protection, inside and out, encapsulating a structural cementitious core.
CORE Cementitious Compound
TOLERANCE
±0.25mm and a flatness tolerance of ±0.5mm measured on a diagonal across the top of the panel
FINISH
ASP’s standard powder coated finish.
CONNECTION
The panel is screw fixed to the pedestal head at all four corners
- Hardened Steel Top Plate
- Moulded Steel Pan Bottom
- Injected Cementiious Core
- Machine Welded
